Single Phase Pump Starter 2.2-4.0kW for Domestic Water Boosting & Circulation

Domestic Water Booster Controller,Circulation Pump Control Panel,Deep Well Pump Control Starter,Single Phase Pump Protector

Product Category

Single Phase Pump Starter 2.2-4.0kW for Domestic Water Boosting & Circulation

Single Phase Pump Starter 2.2-4.0kW for Domestic Water Boosting & Circulation

Product Category : Single / Three Phase Pump Controller - Single Phase Pump Controller

Model: 3S-A11-022, 3S-A11-022-485, 3S-A11-040, 3S-A11-040-485

Working pump: 0.37-4kW

Startup Method: DOL (Direct On Line)

Rated Voltage&Frequency: 90-250V AC, 50/60Hz

Qty of Controlled Pumps: 1 Pump

Control Mode: Manual / Automatic / Timed / Remote

Protections: 13 types protection

Working temperature: -20℃~+55℃

Environment Humidity: 20 to 95% RH, PCB waterproof

Pump Applications: Deep well pump, Booster pump, Submersible pump

Inquiry Online

Email To Us

Leave a message

Product Description

Ideal for domestic tap water boosting and small shop circulation water supply. The lightweight and moisture-resistant ABS enclosure makes this IP65 ABS outdoor smart pump panel suitable for outdoor environments, offering stable and reliable basic control.

Robust Protection & Smart Management

13 Intelligent Protection Mechanisms: Key Protections: Overcurrent, Undercurrent, Overvoltage, Undervoltage, Locked Rotor, Blockage, Frequent Start-Stop, Dry Run, Anti-rust, Signal Loss, and Short Circuit protection.

Fault Record Storage:

Can record the last 10 fault events (displayed as fault name + code on the screen), facilitating historical issue troubleshooting.

Power-Off Memory:

Automatically restores previous settings after a sudden power outage, ensuring continuous operation of your Single Phase Intelligent Pump Starter.

Industrial-Grade Durable Design

IP65 Enclosure: Features a flame-retardant ABS engineering plastic shell with excellent UV resistance and anti-aging properties, ensuring the IP65 ABS outdoor smart pump panel operates stably even when exposed long-term to sun, rain, and wind.

Wide Voltage Input: AC 90-250V easily handles voltage fluctuations, and provides overvoltage and undervoltage protection in this Single Phase Intelligent Pump Starter.

Quality Assurance & Standards

Manufacturing Process

PCB: Triple-proof coating treatment & in-house developed waterproof coating

Inspection: 14-step traceable quality inspection procedures

Product Standard: CE Certified

Types	Standard
EMC	EN IEC 61000-6-1:2019; EN IEC 61000-6-3:2021; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021
LVD	EN 61439-1:2011 EN 61439-2:2011

Technical Specifications

Specification	3S-A11-022	3S-A11-040
Input Voltage	90-250V AC (50/60Hz Auto-adapting)	Same as 3S-A11-022
Max Output Power	2.2 kW	4.0 kW
Control Modes	Manual / Automatic / Timer / Remote (Optional)	Same as 3S-A11-022
Signal Compatibility	Dry contact signals (e.g., float switch, pressure switch, flow switch, electric contact pressure gauge)	Dry contact signals, Analog voltage signal, Analog current signal
Protection Functions	11 Protection Mechanisms Overload, underload, stall, blockage, dry running, signal loss, overvoltage, undervoltage, frequent start and stop, water leakage, rust prevention	13 Protection Mechanisms: Includes: 4-20mA analog signal error, short circuit
Enclosure Material	Flame-Retardant ABS Engineering Plastic	Same as 3S-A11-022
Operating Temperature	-20°C ~ +55°C	Same as 3S-A11-022
Dimensions	15563225mm	324123263mm

Installation Steps

1. After power off, select a well-ventilated, dry location for installation, avoiding direct sunlight.

2. Securely mount the controller using expansion screws

3. Correctly connect the power supply, pump, and signal devices (e.g., float switch) according to the wiring diagram for this IP65 ABS outdoor smart pump panel.

4. After powering on, use the keys to set the control mode and test if the automatic start/stop function operates normally.

Frequently Asked Questions (FAQ)

Q1: Can the timer mode be set for specific time?

A1: The built-in cycle timer operates on "Run Duration + Stop Duration". For specific time-of-day scheduling, an external 24-hour timer can be added.

Q2: After a sudden power outage, does the controller need resetting?

A2: No reset needed. This IP65 ABS outdoor smart pump panel features power-off memory and will automatically resume operation with the last settings once power is restored.
